Steel Wave Profile Corrugated Roofing Sheet Roll Forming Machine

Quantity:
Availability:





Inquire Add to Basket

Product Description

Words From Our Hearts

We are manufacture

We only do high quality machines and we expect to establish long-term cooperation with you

1. CE&ISO&SGS Certification 2. Customization Accepted 3. High Stability and Precision

4. Famous Brand Control System (PLC: Panasonic; Transducer: Yaskawa; Encoder: Omron; Electronics: Schneider)

Products Specification

No	Item	Specification
1	Raw material	galvanized steel; aluminum(according to customer's need)
2	Tolerance	Length tolerance ≤±1mm/10mAngle tolerance≤±1.5mm/10m
3	Dimension	121.51.5m
4	Weight	6 T
5	Working speed	10-15m/min
6	Shipping container	1*20’GP
7	Roller material	45# forge steel, plated with chrome
8	Shaft material	45# forge steel, thermal fining
9	Forming stations	20 stations
10	Driving	by chain

Flow chart

decoiler--guiding--roll forming--hydraulic cutting--out table

No	Component	Quantity
1	Passive decoiler	1 set
2	Guiding	1 unit
3	Roll forming	1 set
4	Hydraulic cutting	1 set
5	Out table	2 sets
6	Hydraulic station	1 set
7	RLC controller	1 set

Product Overview

Passive

1. Bearing capacity: 5 tonne2. Coil inner diameter: 478-538mm
3. Max coil width: 1200mm

Roll forming

1. Motor: 7.5kw WN motor& Hengxing transducer2. Working speed: 20m/min
3. Forming stations： 18 stations
4. Wall panel: 18mm
5. Driving: by chain

Hydraulic cutting

1. Cutting method: roll forming unit stops and cutting starts automatically. After cutting, roll forming unit restarts
automatically.

2. Cutting blade: 1 blade, Cr12 Mov material with vacuum quenching, HRC 58-62°
3. Cutting length can be set automatically as needed

Hydraulic station

1. Hydraulic station provides power for both hydraulic punching and cutting.

2. It's controlled by gear wheel oil pump. The tank
should be filled with 46# hydraulic oil.
3. Hydraulic motor power: 4kw
4. Components: the system includes a set of hydraulic tank, a set of hydraulic oil pump, hydraulic pipes and electromagnetism valves.

PLC controller
